◆ Brand-New Structural Design

• 3 configurations for <7.5KW models

• Rational power distribution, higher cost performance

• European-style terminals with bottom-in & bottom-out wiring

• Shared control board & keypad

• Independent air duct, dust-proof inverter interior

◆ Optimized Hardware Design

• Long-life components + refined design

• Rational component layout

• Switching power supply with output short-circuit protection for top reliability

• High-standard EMC, strong anti-interference capability

◆ High Thermal Conductivity & Insulation Medium

• Alumina ceramic sheets for single-tube heat dissipation

• Drastically lower internal temperature rise

• Excellent environmental adaptability

◆ Rigorous Production & Testing

• Full-automatic conformal coating process

• EFT, surge, electrostatic tests passed (meets industry EMC standards)

• ATE automatic testing for single boards & complete machines

◆ Application of High Thermal Conductivity and High Insulation Materials

Aluminum oxide ceramic sheets are used as the heat dissipation medium for single components.

Significantly reduces the internal temperature rise of single components, resulting in better environmental adaptability.

◆ Rigorous Production and Testing

Uses fully automatic three-proof coating process.

EFT test, surge test, electrostatic discharge test, and other EMC tests all meet industry standards.

Both single boards and complete machines undergo rigorous and comprehensive testing using an ATE automatic system.
