JT330N SeriesThe JT330N series frequency converter is a high-performance vector frequency converter. As the company's future flagship model, this series of frequency converters has undergone thorough market research, adopting a brand-new structural design and optimized hardware and software configuration to achieve higher performance and higher precision motor control. With its stable and reliable operation, this series of frequency converters has earned the trust of a wide range of customers and is widely used in industries such as textiles, papermaking, machine tools, packaging, food, fans, and pumps, as well as various automated production equipmrnt. Applications: Small-power applications include assembly lines, fans, water pumps, food processing, printing and dyeing, packaging, and pharmaceuticals.
Collect
产品编号 JT330N Series
Product features
Product Advantages ◆Superior Overload Capacity Long-term operation within 120% of rated current 150% of rated current, 120 seconds 160% of rated current, 60 seconds 180% of rated current, 10 seconds 200% of rated current, 1 second ◆High Starting Torque 0.5Hz/150%, Open-loop Vector Control 1Hz/100%, V/f Control ◆Low Temperature Rise Sufficient cooling fan and heatsink configuration Optimized design through thermal simulation software Temperature rise of the entire series is controlled within 40℃ ◆New Structural Design Narrow-body structure design of the entire series High power density, small installation space ◆Optimized Hardware and Software Design New hardware design concept More scientific component selection and layout High stability, excellent performance ◆Optimized Vector Control Technology Fast dynamic response and stable torque output during low-frequency operation. Built-in more than 30 fault protection functions to ensure stable and safe system operation. ◆Strictly Selected Top-Tier International and Domestic Components Stable, reliable, and durable products. We select the full range of components, never cutting corners, and strive to provide customers with products that offer exceptional value. ◆ Fully Automatic Conformal Coating Line Uses high-quality conformal coating, providing superior waterproof, dustproof, and corrosion-resistant performance. Employs an independent air duct design to effectively isolate external dust, resulting in better environmental adaptability. ◆ Optimized Speed Tracking Function Enables smooth restarting of running motors. ◆ Built-in Timing, Length, and Counting Functions Meets various special application needs. Specification
